Wavelength range: 190 nm – 1100 nm
Spectral bandwidth: 0.5 nm, 1 nm, 2 nm, 4 nm, 5 nm
Automatic wavelength setting
Replaceable Pre-aligned lamps (Tungsten and Deuterium)
PC scanning software with USB port
| Wavelength | 190 nm – 1100 nm |
| Spectral Bandwidth | 0.5 / 1 / 2 / 4 / 5 nm |
| Optical System | Single Beam, Grating 1200 lines/mm |
| Wavelength Accuracy | 0.3 nm |
| Wavelength Repeatability | 0.1 nm |
| Wavelength Setting | Automatic |
| Photometric Range | 0 – 200 % T, - 0.3 A ~ 3 A |
| Photometric Setting | ± 0.3 % T |
| Photometric Repeatability | 0.1 % T (0 ~ 100 % T) |
| Detector | Silicon Photodiode |
| Light Source | Tungsten Lamp and Deuterium Lamp |
| Stray Light | 0.05 % T (220/360 nm) |
| Stability | ± 0.001 A/h; 500 nm |
| Data Output Port | USB port & Parallel port ( Printer) |
| Noise | ± 0.001 A |
| Baseline Flatness | ± 0.002 A |
| Display | Graphic LCD (320 x 240 Dots) |
| Power Supply | AC 220 / 110 V; 50 / 60 Hz |
| Dimension | 590 x 475 x 250 mm |
| Net Weight | 20 Kg |
| Gross Weight | 26 Kg |
Wavelength range: 190 nm – 1100 nm
Spectral bandwidth: 0.5 nm, 1 nm, 2 nm, 4 nm, 5 nm
Automatic wavelength setting
Replaceable Pre-aligned lamps (Tungsten and Deuterium)
PC scanning software with USB port
Low noise and low stray light
Auto 8-cell holder (Optional)
Get Quote for
Single Beam UV/Visible Spectrophotometer LMUS-A311
